Through-Silicon Vias for 3D Integration (e-book) (used book) | bookbook.eu

Description

Publisher's Note: Products purchased from Third Party sellers are not guaranteed by the publisher for quality, authenticity, or access to any online entitlements included with the product.

Written by an expert with more than 30 years of experience in the electronics industry, Through-Silicon Vias for 3D Integration provides cutting-edgeinformation on TSV, wafer thinning, thin-wafer handling, microbumping and assembly, and thermal management technologies. Applications to highperformance, high-density, low-power-consumption, wide-bandwidth, and small-form-factor electronic products are discussed.

This book offers a timely summary of progress in all aspects of this fascinating field for professionals active in 3D integration research and development, those who wish to master 3D integration problem-solving methods, and anyone in need of a low-power, wide-bandwidth design and high-yield manufacturing process for interconnect systems.

Coverage includes:

• Nanotechnology and 3D integration for the semiconductor industry
• TSV etching, dielectric-, barrier-, and seed-layer deposition, Cu plating, CMP, and Cu revealing
• TSVs: mechanical, thermal, and electrical behaviors
• Thin-wafer strength measurement
• Wafer thinning and thin-wafer handling
• Microbumping, assembly, and reliability
• Microbump electromigration
• Transient liquid-phase bonding: C2C, C2W, and W2W
• 2.5D IC integration with interposers
• 3D IC integration with interposers
• Thermal management of 3D IC integration
• 3D IC packaging
